Lightweight Steel Construction Light Steel Framing Manufacturer Metal Light Gauge Steel Beams Box

Place of Origin Zhejiang,China
Brand Name FASEC
Certification CE ,ISO,SGS
Model Number HZFC No.888
Minimum Order Quantity 5 sets
Price USD 200 Per Square Meter
Packaging Details by seaworthy package
Delivery Time 8-15 working days
Payment Terms L/C, T/T
Supply Ability 100000 square meters per month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Product Type LGS Structure Product Name Hot Dip Galvanized Anti Slip Bar Steel Grating Weight,Galvanized Expanded Metal Lowes Weight Per Square Meter Steel Grating
Color Silver,Customers Samples Color,black,White Type Press Welded Steel Grating
Length Customized-Made Material G550,Q235
Thickness Customized Usage Light Steel Villa
High Light

lightweight steels framed buildings G550 Q550

,

G550 Q550 lightweight steels framed building

,

light gauge metal framing box beams

Leave a Message
Product Description

Prefabricated Light Beam Structure Frame China Steel Fabrication with Steel Structure Frame

Speficiations of Prefabricated House



Type With or without steel chassis

Type one: without steel chassis, build on concrete strip foundation

Type two: with steel chassis, the building will be put on concrete blocks

Story One storey or two storey or three storey are available
Frame system Steel column Q235 Steel, 100*100*2.5 square tube, alkyd painting, twice primer paint & twice finish paint
Steel roof truss C100*40*15*2.0, welding and galvanized
Roof and wall purlin C100*40*15*2.0, galvanized
Cross bracing Q235 Steel, L40*3 angle steel, alkyd painting, twice primer paint & twice finish paint
Chemical bolt M16, chemical bolt
Ordinary bolt 4.8S, galvanized
Steel chassis or 1st floor system Main beam HN250*125*5.5*8, Q235 Steel, alkyd painting, twice primer paint & twice finish paint
Secondary beam C100*40*15*2.0 galvanized
Floor structure board 18/20mm plywood and fiber cement board
Flooring PVC floor leather and ceramic tiles are available
Wall and Roof system Wall panel

Sandwich panel: Rock wool, Glass wool, EPS, PU are available

Thickness: 50mm, 75mm, 100mm, 150mm, 200mm are available

Roof panel

Sandwich panel: Rock wool, Glass wool, EPS, PU are available

Thickness: 50mm, 75mm, 100mm, 150mm, 200mm are available

Ceiling system Dry room 600*600*6mm gypsum board,with framework
Wet room 600*600*5mm calcium silicate board, with framework
Door and window system Door Fire resistant steel single/double door, emergency door with panic bar, aluminum glass door, MDF door are available
Window PVC, Aluminum sliding window with single/double glazed glass, with mosquito screen, with louver are available
Electric and Plumbing system Electric units Electric wire, conduit, socket, switch, light, distribution box
Sanitary units Shower, closestool, basin, water pipe

Advantage

(1) Light steel house's structure parts produce as manufacturing factory type and high degree of mechanization, high degree of commercialization .

(2) Light steel housing construction speed is fast, it is a civilization construction and will not affect the nearby residents

(3) The steel structure of light gauge steel house is a sustainable development product of environmental protection.

(4) Light steel house is light weight, seismic performance is good.

(5) Because of the wall thickness of light steel structure housing is smaller .It can increase the effective use of the area than the brick concrete structure .

(6) Compared to the light steel structure building with reinforced concrete residential, due to the light steel structure of the steel after recycling, but concrete cannot be recycled. later must be construction waste, causing environmental pressure and concrete need 40 years to completely dry, so easy to cause the indoor humidity, wet, is not conducive to human health. But light steel structure completely without concrete, and therefore does not exist the problem.

(7) Light steel housing have good anti-seismic performance . Due to the seismic activity is about and activities, so screw nail is tight with light steel structure to composed of a safety box, can't because of the earthquake shaking and collapse of the wall or floor fall endangers the personal safety.

(8) Light steel building construction using dry construction method, will not cause the waste of water , and save the cost .

   If you have  any questions ,please contact us Grace@hfsteelstructure.com /Nura@hfsteelstructure.com.We will provide one-stop  service. And we have professional  engineers.
